Orange-500 DNA Size Standard (500 bp) 400 µL

SKU: DSMO-100
DSMO-100
Product Information

Cost-efficient fluorescent size standards for ABI Genetic Analyzers

Format

The Orange-500 DNA Size Standard is for use with five-dye or six-dye spectral calibration Genetic Analyzers, such as 3130, 3500 and 3730 and SeqStudio™ series.

The Orange-500 DNA Size Standard is a fluorescent labeled ultra-accurate internal size standard for the reproducible sizing of fragment analysis peaks during capillary electrophoresis and precise DNA fragment size comparisons between capillary electrophoresis runs.

Compatibility

This fluorescent size standard can be used for a variety of applications like Microsatellites, MLPA, Fragment Length analysis, Fragment Length Polymorphisms etc. Each of the DNA fragments is labeled with a LIZ® compatible fluorophore resulting in sharp orange peaks under denaturing conditions.

Premium features
Downloads
Premium features

The DNA Size Standard contains 16 Orange dye-labeled, single-stranded fragments in the 45-595 nucleotides range with respective basepair lengths of 35, 50, 75, 100, 139, 150, 160, 200, 250, 300, 340, 350, 400, 450, 490 and 500 bp.

This size standard can be combined with fragments, labeled with the dyes FAM™, VIC®, NED™, PET® (DS-33 / Dye Set G5) or with FAM™, VIC™, NED™, SID™, TAZ™ (DS-36 / Dye Set J6). Each kit contains sufficient standard for at least 800 analyses.

Cost-effective alternative for GeneScan™ size standards
Uniform peak height
